1 Port Type-A Fiber Optic Distribution Outlet Box
Product Inquiry
Kindly send us your product you want or project details. We will quote for you within 24 hours!
This 1 Port Type-A fiber optic outlet box is designed for specific environment, e.g., high-density indoor use / FTTH deployment / wall-mount scenarios. Compared with other models, it features dual-layer structure. Made from high-quality ABS, it ensures reliable performance for both singlemode and multimode fibers.
- Ultra Compact Design: Optimized size (only 23mm thickness) for use in desktop/wall-mounting.
- Strong Mechanical Performance: Supports proper fiber bending radius and offers effective protection for incoming/outgoing fibers.
- Adapter Compatibility: Supports 1 SC Duplex APC/UPC or 4 LC Duplex APC/UPC adapters.
- Cold Connector Compatibility: Supports direct connection of cold connectors, tail fibers, or drop cables without additional splicing.
- Dust Protection: Equipped with clamshell-style dustproof cover for better cleanliness.
- Easy Snap-Fit Design：Equipped with a snap-fit latch system that offers both secure closure and convenient tool-free disassembly.
- Flexible Adapter Mounting: Internal position for better protection.
Product Specifications
| Product Name： | Fiber Optic Distribution Outlet Box | Application: | FTTX |
| Port: | 1 Port | Adapter Capacity: | 2pc |
| Size((H*W*D): | 117mm*86mm*23mm | Weight: | 80g |
| Color: | White | Adapter Type: | SC Simplex / LC Duplex |
| Fiber Mode: | Singlemode/Multimode | Work Enironment: | Indoor |
| Working Temperature: | -40℃~+65℃ | ROHS Compliancy Status: | Compliant |
| Application: |
FAQ
What type of fiber adapters does this termination box support?
It supports 1 SC duplex or 1 LC quad adapters, compatible with both single-mode and multimode fibers.
Is this termination box suitable for indoor use?
Yes, the compact design and white ABS material make it ideal for wall-mounted indoor FTTX or telecom network applications.
Does the box come with pre-installed adapters?
No, adapters are sold separately, allowing flexibility based on your installation needs.
How is the cable fixed inside the box?
The box includes internal cable management features for secure fiber routing and fixation.
